EFD20 EFD25 EFD30 Math o Transformer Amlder Uchel ar gyfer PCB Power for Ad i DC Converter
Gadewch neges
1). Ffeithiau:
Mae ganddi wrthwynebiad cryf, cynhwysedd wedi'i ddosbarthu, rhwystr, gwanhau trawsyrru isel, cwmni
strwythur, awyru'r inductan, ac ati, yn cael eu defnyddio'n eang mewn ffacs
peiriannau, PBX.
2). Amrediad amledd perthnasol: 20 i 100kHz:
Amlder gweithredu: uwch na 200kHz
Fflwcs magnetig uchel a deunyddiau magnetig colli isel
Gyda inductance gollwng isel ac effeithlonrwydd uchel.
3). Cymhwysiadau:
Cylchedau PCB, cyfrifiadur, teledu, monitro, sganiwr, dyblygu, addaswyr symudol, argraffydd a chyfarpar eraill a
offerynnau.
System inswleiddio UL ar gyfer Dosbarth B (130), F (155), H (180)
4). Yn gallu gwneud trawsffurfwyr Ferrite eraill wedi'u haddasu:
Amrediad pŵer: math craidd gan ddefnyddio deunydd gradd N67
<5: rm4,="" p11="" 7,="" ef12.6="" ac="">
5 i 10: E (F) 16, RM5 a P14 / 8
10 i 20: RM6, E (F) 20, P18, U15 ac EFD15
20 i 50: RM8, P22, RM10 ETD29, E25 ac EFD20
50 i 100: ETD29, ETD34, RM12, P30 ac EFD25
100 i 200: ETD34, ETD39, ETD44, P36, E30, E42 ac EFD30
200 i 500: ETD44, ETD49 ac E55
> 500: ETD54, ETD59 ac E65
| Model | Pin | Dimensiwn | ||||
| A | B | C | D | E | ||
| EFD-12 | 8 | 6 | 17 | 20 | 3.0 | 13.5 |
| EFD-15 | 10 | 7.3 | 18.2 | 21.35 | 2.5 | 15 |
| EFD-15 | 10 | 7.5 | 19.3 | 22.6 | 3.0 | 16.7 |
| EFD-20 | 10 | 9.4 | 25.3 | 27.7 | 3.75 | 21.7 |
| EFD-20 | 12 | 9.7 | 24 | 26.8 | 3 | 20 |
| EFD-25 | 10 | 13.4 | 29.7 | 35.4 | 5 | 25 |
| EFD-25 | 10 | 12.6 | 29.7 | 31.5 | 5 | 25 |
| EFD-30 | 12 | 12.6 | 31.6 | 35.5 | 5 | 30 |
Paramedrau Trawsffurfydd Amlder Uchel Cysylltiedig Eraill:
Tabl1: Paramedrau Trawsffurfydd Math EE
| Trawsnewidydd math EE | |||||||
| Rhan Rhif | Terfynell Pinsin | Dimensiwn mm | Math | Paramedr trydanol | |||
| A | B | C | Inductance | Pŵer allbwn (W) | |||
| EE-8.3 | 6 | 8.0 | 8.0 | 8.3 | V | 100.0uH | 0.2-3.0 |
| EE-10 | 8 | 11.5 | 10.2 | 10.2 | V | 80.0uH | 0.5-5.0 |
| EE-13 | 10 | 12.0 | 12.5 | 13.0 | V | 120.0uH | 0.5-8.0 |
| EE-16-1 | 6 | 14.8 | 13.3 | 16.0 | V | 90.0uH | 1.0-10.0 |
| EEL-16 | 10 | 28.5 | 16.0 | 21.9 | V | 600.0uH | 2.0-15.0 |
| EE-19-1 | 8 | 17.6 | 16.0 | 19.0 | V | 800.0uH | 3.0-30.0 |
| EEL19 | 10 | 31.5 | 16.0 | 21.1 | V | 1200.0uH | 3.0-30.0 |
| EE-25-1 | 6 | 20.0 | 18.2 | 25.2 | V | 2000.0uH | 3.0-45.0 |
| EEL25 | 8 | 35.3 | 17.5 | 25.2 | V | 2800.0uH | 3.0-45.0 |
| EE-30 | 10 | 21.0 | 29.2 | 30.0 | H | 900.0uH | 3.0-50.0 |
| EE-40 | 14 | 27.6 | 30.5 | 40.0 | H | 1500.0uH | 3.0-55.0 |
| EE-42 / 15-1 | 12 | 33.8 | 44.0 | 42.0 | H | 2000.0uH | 3.0-80.0 |
| EE-42 / 20-1 | 12 | 45.0 | 39.8 | 42.0 | V | 1900.0uH | 3.0-90.0 |
| EE-55 | 20 | 50.0 | 50.0 | 55.0 | H | 3000.0uH | 3.0-150.0 |
| EE-65 | 16 | 55.2 | 51.8 | 65.0 | H | 4500.0uH | 3.0-300.0 |
Tabl2: Paramedrau Trawsnewidyddion EPC
| Model | Dimensiwn (mm) | VA | Pwysau | |||
| A | B | C | f = 50KHz | f = 100KHz | g | |
| EPC-9.5 | 10 | 5.5 | 10 | 1.1 | 2.5 | 9 |
| EPC-13 | 14 | 9 | 14 | 5 | 8 | 11 |
| EPC-17 | 19 | 11 | 18 | 14 | 20 | 18 |
| EPC-19 | 20 | 13 | 21 | 18 | 27 | 21 |
| EPC-25 | 27 | 17 | 26 | 36 | 59 | 29 |
| EPC-27 | 29 | 17 | 36 | 52 | 75 | 35 |
Tabl3: Paramedrau Trawsffurfydd math ER
| Manyleb Trawsffurfydd ER | |||||||
| Model | PIN | Dimensiwn | |||||
| A | B | C +/- 0.5 | D +/- 0.5 | E | F | ||
| ER25.5 | 8 | 19.5 | 19.7 | 12.5 | 4 | 5 | 25.5 |
| ER28 | 12 | 30.5 | 23 | 17.5 | 4 | 5 | 31 |
| ER28 | 12 | 23.1 | 28.2 | 25 | 4 | 5 | 29.1 |
| ER28 | 12 | 36 | 27 | 20 | 4 | 5 | 30 |
| ER28 | 12 | 26.3 | 37.1 | 30 | 4 | 5 | 30.2 |
| ER33 | 14 | 37.5 | 28 | 22.5 | 4 | 5 | 36 |
| ER35 | 14 | 43.5 | 28 | 22.5 | 4 | 5 | 35.5 |
| ER35 | 16 | 29.1 | 40.3 | 35.4 | 4 | 5 | 40.3 |
| ER39 | 16 | 46 | 31.1 | 25 | 4 | 5 | 43.1 |
| ER39 | 16 | 33 | 41.5 | 30.85 | 4 | 7.5 | 42.3 |
| ER40 | 16 | 48 | 31.1 | 25 | 4 | 5 | 43.1 |
| ER4215 | 14 | 45.5 | 30 | 25 | 4 | 5 | 42 |
| ER4220 | 14 | 44 | 37.5 | 36 | 4 | 5 | 42 |
Tabl4: Paramedrau Trawsnewidyddion PQ
| DIMENSIONS COILFORMER (mm) | |||||||||||||||
MATH | A | B | C | D | E | F | G | H | Fi | J | K | L | M | N | O |
PQ20 / 16 | 23.15 | 17.35 | 23.15 | 20.3 | 2.5 | 9 | 3.8 | 5.1 | 17.9 | 9.7 | 7.82 | 10.8 | 2.4 | 0.6 | 7.35 |
PQ20 / 20 | 23.15 | 17.35 | 23.15 | 20.3 | 2.5 | 9 | 3.8 | 5.1 | 22 | 13.85 | 12 | 10.8 | 2.4 | 0.6 | 7.35 |
PQ26 / 20 | 26.6 | 21.85 | 29.75 | 25.4 | - | 12.3 | 3.8 | 7.6 | 21.5 | 11.05 | 9 | 14.2 | 2.4 | 0.65 | 7.2 |
PQ26 / 25 | 26.6 | 21.85 | 29.75 | 25.4 | - | 12.3 | 3.8 | 7.6 | 26.05 | 15.65 | 13.55 | 14.2 | 2.4 | 0.65 | 7.2 |
PQ32 / 20 | 32.15 | 26.7 | 34.3 | 30.5 | - | 13.85 | 5.1 | 7.6 | 22.35 | 11.05 | 8.9 | 15.9 | 2.8 | 0.75 | 7.2 |
PQ32 / 30 | 32.15 | 26.7 | 34.3 | 30.5 | - | 13.85 | 5.1 | 7.6 | 32.15 | 20.85 | 18.7 | 15.9 | 2.8 | 0.75 | 7.2 |
PQ35 / 35 | 35.00 | 31.0 | 39.0 | - | - | 15 | - | - | 37.4 | - | 22.4 | 16.9 | |||
)Mantais:
1.UL, CUL, CE, ISO9001: 2008
2. Rydym yn cynnig trawsnewidyddion wedi'u gwneud yn arbennig, mae croeso i OEM ac ODM
3. Rydym yn darparu'r ansawdd rydych chi'n ei ddisgwyl ar brisiau cystadleuol yn gyson
4. Oes ansawdd trawsffurfydd: 10 mlynedd.
Gwasanaeth gwerthu 5.Specialty: 5 -10 mlynedd
6. Prawf Trosglwyddo: prawf 100% cyn y cludo
